0510615317 REXROTH HYDRAULIC GEAR PUMP AZPF-11-016LCP20KB-S0007
$713.00
Skip to product information
0510615317 REXROTH HYDRAULIC GEAR PUMP AZPF-11-016LCP20KB-S0007
Technical Specs
Product attributes
Nominal size [cm³/rev] 16.0
Max.intermittent pressure [bar] 280.0
Maximum rotational speed [rpm] 2950.0
Drive shaft Tapered keyed 1:5
Direction of rotation Counter-clockwise rotation
Front cover 2-bolt dia. 50 mm (option 2)
Housing material Aluminum
Noise level Standard noise level
Customer part number 00816857
Product External gear unit
Function Pump
Model High perf (F) (4..28 cm³/rev)
Series Bearing diameter 18 mm
Version Phosphated, aligned covers
Port connection Square flange (German version)
Sealing material NBR, shaft seal in FKM
Rear cover Standard (cast iron)
Non-standard version Deviations from catalogue standards, see drawing
Weight [kg] 3.5
0510615317 REXROTH HYDRAULIC GEAR PUMP AZPF-11-016LCP20KB-S0007
$713.00
